exterior appearance details
main frame:Hot-dip galvanized seismic-resistant steel structure thermal break system, total thickness: 100mm
shell:Aluminum alloy single panel 2.0mm thick (national standard), with metal fluorocarbon baked paint finish
insulation system:Fire-resistant board + rock wool (50 mm rock wool installed in double layers with staggered joints, fire rating B1) or extruded polystyrene board (XPS) (combustion performance rating B2, thermal conductivity ≤ 0.028 W/m·K, suitable temperature range: +30°C to –20°C).
glass curtain wall:LOW-E 6+12+6 Insulated Tempered Glass(Suitable temperature range: +30°C to -20°C)
window and door system:customized thermal break aluminum system windows
electric skylight:6mm + 1.52mm PVB interlayer + 6mm + 12mm air space + 6mm laminated insulating Low-E tempered glass
external ambient lighting:LED ambient lights
entrance door:Waterproof outdoor smart lock for hotels
electrical equipment room:Lifting ring/Transportation fixing device/ Connector
Tire:Tire
Trailer coupling:Trailer coupling
Support foot:Support foot
flooring system:15 mm magnesium oxide board (waterproof, fire-resistant, moisture-resistant)
wood floor:1.5 mm sound insulation cushion + 3.5mm three-layer solid wood geothermal floor or stone plastic .UL 2818-2022 Gold Certification Criteria for Building Products and Interior Finishes
One wall system:baseboard
wall system:light steel stud frame+WPC
ceiling system:Fire-resistant board (fire rating B1) + Bamboo-Wood Fiberboard (fire rating B1)
Interior lighting:Downlight、Linear light
Curtain track:Curtain track
Smart control system
Smart power control system:Card-operated power on/off
Electrical appliances /Utilities
electrical system:Whole-house cable 10 sqmm main entry + 8-core network cable
Conduit:PVC insulated conduit
piping for water supply and drainage:Whole-house water supply and drainage explosion-resistant and pressure-resistant piping . At 20 °C, 1 hour, 16 MPa hoop stress: no rupture, no leakage.At 95 °C, 22 hours, 4.3 MPa hoop stress: no rupture, no leakage.
air conditioning:1 units of Midea 1.5 HP wall-mounted air conditioners
Socket:Five-pin socket / Three-pin socket(5 units)
switch panel:Control switch panel (3 units)
water heater:electric water heater (60L)
Bathroom fittings
ceiling:Fire-resistant board (fire rating B1) + Bamboo-Wood Fiberboard (fire rating B1)
bathroom wall panels:Fire-resistant board (fire rating B1) + Bamboo-Wood Fiberboard (fire rating B1)
bathroom door:Bathroom privacy door (one-way frosted tempered glass)
floor:Floor tiles.
Showerhead:Multi-function showerhead
bathroom heater:5-in-1 bathroom heater with lighting, ventilation, and heating
toilet:High-end toilet
bathroom shelf:space aluminum towel rack
Tissue Box:Waterproof Space Aluminum Tissue Box
Towel bar:Towel bar
tap:Brand faucet
Mirror with silver coating:Mercury mirror
Basin:washbasin
Outer packaging:Outer packaging protection Off-site lifting
Cabin bonding process:Cabin bonding process
optional main structures materials:
insulation system:Polyurethane replaces extruded polystyrene (XPS) .Polyurethane (flammability rating: Class B1; thermal conductivity: 0.018–0.024 W/m·K)
Glass:6-9-6-9-6 Triple-pane Tempered Low-E Insulating Glass Unit
Underfloor Heating:Graphene-Enhanced Carbon Fiber Plate+Calcium silicate board (for underfloor heating)
wall heating system:Graphene-Enhanced Carbon Fiber Plate+Calcium silicate board (for wall heating)
Water Pipe Heat Trace Cable:Water pipe heat trace (for supply and drainage pipes)
wall system:Calcium Silicate Board+WPC
ceiling system:Aluminum panel ceiling
air conditioning:Hisense / Hitachi,One 2-ton air conditioners
Lightning and Electric Shock Protection System:External Lightning Protection System and Bathroom Equipotential Bonding for Electric Shock Prevention
motor:motor (excluding curtains and sheer curtains)
tatami:tatami
intelligent control: intelligent voice intercom
intelligent control:10-inch Center Control Screen
intelligent contro I:Smart Speaker(1set)
Smoke detector:Smoke Detector – Monitors Smoke Concentration & Triggers Fire Prevention Alarm
Sprinkler system:Sprinkler system
Projection Screen for International Markets:Projection Screen for International Markets
